The X-Effects LED and X-Effects LED HO RGBW Projectors are colour-mixing fixtures that create dynamic lighting effects in wide range of indoor or outdoor applications. Effects are created by projecting coloured light through the edges of two rotating pieces of Effects Glass that are mounted off-centre of the optical path. This results in a projection with linear motion for creating reflected water, blowing fire, northern lights and other vivid, animated lighting effects.
Please note that the X-Effects LED Projectors do not ship with a lens. Choose from the available four lens accessories when ordering to achieve the beam spread your project requires.
Full range of effects can be seen HERE
Bright, Vibrant Lighting Effects
The X-Effects LED Projectors feature either 1,400 or 3,000 (HO) lumens of output of 45 and 90 watts (HO) of power. The X-Effects LED HO can maintain over 100 lumens at 65ft+ (20m+).
Designed For Use Indoors Or Outdoors
The X-Effects LED Projectors are IP65-rated for indoor or outdoor use, offering the versatility to create dynamic lighting effects anywhere they are required.
Four Available Lens Options
Whether you need to shine your effect on a building across the street or on a wall five feet away, the X-Effects LED Projectors have the proper lenses to meet every projection need.
Customizable Effects Engines
The X-Effects LED Projectors can achieve a variety of different lighting effects by changing gobos or adding color into either the Static Gobo/Filter position or into the two rotating Dynamic Effects Glass positions.
Quiet Operation
Lighting effects should be seen, not heard. The X-Effects LED Projectors are passively cooled enabling them to operate without noisy fans.
Manual & DMX Controls - RDM Compatible
The X-Effects LED Projectors feature on-board controls of the fixture’s output, as well as the speed and direction of both Effects Glass Gobos. The fixtures can also be controlled via DMX and are RDM compatible.
- Additional Information
Introducing The X-Effects® LED Projector
We’re thrilled to announce the introduction of the X-Effects LED Projector – the next generation of dynamic lighting effects from Rosco.
Over the past 15 years, the X24 X-Effects Projector has captured the imagination of lighting professionals in all of Rosco’s core illumination markets as it became one of Rosco’s most popular light fixtures. Best known for its signature water effect seen in aquariums and restaurants all around the world – this fixture’s unique effects-engine has also created captivating light art inside museums and realistic lighting effects on stage.
Now there is a new way to create those same lighting effects using a compact, power-efficient LED fixture. The X-Effects LED Projector is available in two models that project bright, vibrant lighting effects – a cool white, 5500K unit and a colour-mixing RGBW unit.
Both models feature bright output, are capable of 33’ (10m) throws, and feature four lens accessories to choose from – enabling designers the ability to adjust the fixture’s beam spread to their project.
Just like the X24, the standard X-Effects Glass that ships with the fixture can be swapped out to create other lighting effects. Effects Glass Gobos such as Image Glass and ColourWaves, for example, can be used to create mesmerizing lighting effects, and Custom Gobos can be ordered for the fixture to add messaging or stylized textures and patterns.
Another new feature of the X-Effects LED Projector is its IP65 rating. The most common request for the X24 was to release a model that could be installed outdoors. Whether it’s water effects for aquariums, fire effects for casinos or falling snowflakes for retail stores and themed attractions – designers have requested a way to project lighting effects onto the facades of buildings. Until now, that was only possible by purchasing large, expensive enclosures. The X-Effects LED Projector is IP65 rated, which means its effects can be projected wherever they’re needed - indoors and outdoors.
The X-Effects LED Projector is fully dimmable and features both onboard controls and RDM-compatible DMX controls. Three knobs provide manual control of the dimming and speed/direction of the two pieces of X-Effects Glass inside the fixture. The fixture’s DMX and RDM capabilities not only control dimming & speed/direction, it also provides remote addressing of the fixture plus colour control of the RGBW fixture.
We can go on-and-on about all of the bells and whistles of the new X-Effects LED Projector – but it’s the EFFECTS that it can generate that should take centre stage. The next time your design calls for vibrant lighting effects that need to travel in a linear direction – remember that Rosco has the solution and visit the X-Effects LED Projector page on our website.
Specifications of the X-Effects projector
Input Voltage: 100-240VAC
Power Consumption: 45 and 90 (HO) Watts at maximum output
Output: 1,400 and 3,000 (HO) lumens
Color Temperature (White LED): RGBW
Lumen Maintenance: 50,000 hours at 45C (LM-79-08)
Power/Data Connection: Male UTL Connector on rear panel
North America: 6-ft (2m) insulated cable harness with mating female UTL connector.
AC In, DMX 512 In/Out - unterminated
Non-North America: Hybrid power/data cable with mating female UTL connector.
AC In, DMX 512 In/Out - unterminated
Number of DMX Channels: 8
RDM compatible
Operating Temp.: -13° to 113° F (-20° to 45° C)
IP Rating: IP65
Dimensions: 5.5”L x 10.1”W x 5.8”H (14.2cm x 25.8cm x 14.8cm)
5.5”L x 10.1”W x 6.5”H – HO (14.2cm x 25.8cm x 16.7cm - HO)
Weight: 9 lbs (4.1 kg)
13 lbs (5.8kg) HO
Housing: Powder Coated Aluminum
Approvals:
ETL / UL Standards #1573 and # 8750
cETL / CSA C22.2 #166
CE
