Evica EP+ SuperWide Gobo Projector

Evica EP+ SuperWide Gobo Projector

In the world of lighting design and projection, space constraints can be a significant challenge. Traditional gobo projectors often require a considerable throw distance to create a usable image, making them unsuitable for locations with limited width or height. This limitation has long hindered the creative possibilities for lighting designers and projection enthusiasts, confining their projects to spaces where the projector can fit.

Enter the EP+ SuperWide, a groundbreaking solution that addresses this exact problem. With its entirely new lens system, the EP+ SuperWide halves the required throw distance, allowing for gobo projection in spaces previously deemed impossible. This innovation marks a first in the industry, pushing the boundaries of what’s achievable and opening up new creative horizons.

Currently available as a powerful 40-watt version, the EP+ SuperWide offers a robust solution right out of the gate. But the innovation doesn’t stop here—more powerful versions are on the horizon, promising even greater flexibility and impact for your projection needs.

We also offer a picture framing version with iris options for galleries. The SuperWide’s beam uniformity offers outstanding illumination for framing exhibits and artworks

Built with the same rugged, high-quality construction that defines all Evica products, the EP+ SuperWide combines durability with cutting-edge technology. It ensures that you no longer have to compromise on the size or quality of your projected image due to spatial constraints.

Say goodbye to the limitations of traditional projectors and welcome a new era of flexibility and innovation in your lighting designs. Whether you're working in a cramped venue or a location with challenging dimensions, the EP+ SuperWide offers the perfect solution, making it a must-have tool for any lighting designer or projection user.

Elevate your creative projects with the EP+ SuperWide and transform the way you think about gobo projection.


PLEASE NOTE THIS IS A FIXED LENS PRODUCT ANDN LENS AND STANDARD DRIVER  IS INCLUDED


DOWNLOAD EP+ SUPERWIDE SPEC SHEET HERE



£0.00 ex. VAT
£0.00 inc. VAT
£935.00 ex. VAT
£1,122.00 inc. VAT
Earn0
reward points

Power Drive


  • Additional Information

    Technical details EP+ Super Wide

    Cooling Convection

    Noise dBA         0

    IP rating            IP65

    Operating Temperature Degrees            C -20 to +40

    Light Source Fidelity      40W

    LED Luminous Flux (Lm)             6500K/ 5250  (Options 3000K/5600K 2400/4200)

    Standard CCT    6500K  (Options 3000K/5600K/UV 395nm 30’000mW)

    Standard CRI 80 (Options 98+)

    Luminaire Supply Voltage (Vdc)              48

    Luminaire supply current (mA)   1200

    Input Power      45w

    Recommended IP67 Drive module (on board dim)          XLG-50-A

    Recommended IP67 Drive module (0-10V dim for 100K pot)       XLG-50-AB

    Recommended IP67 Drive module (Dali dim)      ELG-75-C1050-DA

    Lamp housing material              Aluminium

    Lamp housing finish (standard)              Anodised

    Lamp housing finish (special order)        RAL Powder coated

    Weight (Kg)       1.8

    Gobo Size         E 37.5mm (active 28mm)

    Mounting Yoke hole      13mm

    Objective Lens    Super Wide 15mmfl (approx 50º image angle)

    LED Lifetime (LM-70)     43,000 Hours (70% Lumen Maintenance)

    Options

    Cowl     C1

    Integrated Drive Mounting plate            XLG-BRACKET
